Genius Dry Bath Incubator, MD series, MD-01N / MD-02N
MD-01N / MD-02N come in either single or dual block models, along with a complete set of interchangeable blocks.
Product
The Genius Dry Bath Incubators come in either single or dual block models, along with a complete set of interchangeable blocks. It is designed for a variety of applications, including restriction digest, denaturing DNA melting agar, coagulation studies, hybridization and hot start thermo-cycled reaction. The microprocessor controller offers highly accurate temperature control, rapid heating and excellent stability. The temperature can be set in increments of 0.1°C from 5°C above ambient to 150°C. An optional temperature probe is available to place directly in samples. A timer can be set from 1- 999mins. The MD series can be used as a mini water bath or bead bath. Optional function control software allows the dry bath incubator to perform real-time data recording through a PC.
 |
 |
 |
| with beads | with water | with block |
MS06_Genius Dry Bath Incubator MD-01 / MD-02 * Marketing video
- Digital microprocessor offers precise performance control
- Highly accurate temperature control and broad control range
- Rapid heating rate
- Digital LED display & timer
- User temperature calibration
- Molded aluminum alloy chamber
- Function control software available
* All images are for reference only, actual products might differ from the pictures above.
* Technical specifications subject to change without notice.
 |
|
 |
|
| Cat. No. | MD-01N (Single Block) | MD-02N (Dual Block) |
|---|---|---|
| Display | LCD | |
| Power | 125W | 200W |
| Dimension (WxLxH) | Approx. 7.9"x11.7"x3.2" (200x298x88mm) | |
| Controller | Digital microprocess controller | |
| Heating chamber | Molded Waterproof aluminum alloy coated with PTFE | |
| Temperature control range | 5°C above ambient to 150°C** | |
| Temperature Increment | 0.1°C | |
| Temperature Uniformity | ±0.2°C at 37°C | |
| Temperature Accuracy | ±0.2°C at 37°C | |
| Temperature Calibration | Yes | |
| Timer | 999 (min) / Continuous | |
| Safety | Leak proof heating chamber | |
| Over temperature protectionn | ||
| SSR failure detection | ||
| Operating temperature | Ambient to 40°C | |
| Special Feature | Can be used as water bath or bead bath incubator | |
| Block material | Aluminum alloy | |
| Block type | Standard and customized type are available | |
| PC Connection | RS232 | |
| Rated voltage | 110V / 220V | |
| Weight | Approx. 4.6lb (2.1kg) | Approx. 6.2lb (2.8kg) |
| Blocks | ||
| Block material | Aluminum alloy | |
| Dimension (WxLxH) | Approx. 3.1"x4.1"x2" (79x104x50mm) for standard type | |
| Block lifter well | Yes | |
| Thermometer well | Yes (except microplate blocks) | |
**For prevent temperature difference effect and keep temperature stable, PQ is required in high temperature control mode(>=140 °C ) or contact the local dealer before ordering.
***For the thermoblock requirement of dual block unit, please discuss with local dealer before order.
| Cat. No. | Product Description |
|---|---|
| MD-01N-110/220 | Genius Dry Bath Incubator (One block unit); without block |
| MD-02N-110/220 | Genius Dry Bath Incubator (One block unit); without block |
| Cat. No. | Product Description |
|---|---|
| MD-RS232 | RS 232 cable |
| MD-PCSW | Data record and function control software package |
| MD-PCSW-R | Data record and function control software package, including a RS232 cable |
| Cat. No. | Product Description |
| MD-MP01-S | For microplate; titerplate (Plain Block for Single Block unit only) |
| MD-MP01-D | For microplate; titerplate (Dual Block unit only) |
| MD-MP02-S | For 96 wells deep microplate or PCR plate ( for Single Block unit only) |
| MD-MP02-D | For 96 wells deep microplate or PCR plate ( for Dual Block unit only) |
| MD-B0.2 | For 0.2ml tube, 64 wells (or 0.2ml PCR strip tube for 8 wells x 8) |
| MD-B0.5 | For 0.5ml tube, 20 wells |
| MD-B1.5 | For 1.5ml tube, 20 wells |
| MD-B1.5V | For 1.5 V-shaped tube only, 20 wells |
| MD-B0.5+1.5 | Combination: for 0.5ml tube, 12 wells; and for 1.5ml tube, 12 wells (on the same side) |
| MD-B0.5/1.5 | One side for 1.5 or 2.0ml tube, 20 wells and another side for 0.5ml tube, 30 wells (on the opposite side) |
| MD-B13 | Well size 13mm, 20 wells |
| MD-B17 | For 15ml centrifuge tube, 12 wells |
| MD-B20 | Well size 20mm, 12 wells |
| MD-B25 | Well size 25mm, 6 wells |
| MD-B29 | For 50ml centrifuge tube, 4 wells |
| MD-BD01 | Single bead MD dry bath block, (WxLxH) 79 x104x76mm |
| MD-BD02 | Dual bead MD dry bath block, (WxLxH) 104 x158x76mm |
| MS-BL95-E | Block Lifter, 95mm length with E-type retaining rings |
