Automatic Mass flow controlled Gas Mixing Station is designed to have more precise gassing control and quicker response. Supplying up to four gases allows you to optimize a variety of cell and microorganism applications. Automatic oxygen and nitrogen control is able to remain the desired dissolved oxygen (DO) level and create anaerobic environments easily. Moreover, carbon dioxide supply provides you an option to control the pH of culture conditions without liquid acid addition.
Control gases | Air, N2, O2 and CO2 | ||||
---|---|---|---|---|---|
Control parameter | DO and pH | ||||
Components | 4 Mass Flow Controllers | ||||
DO cascade | One-way (O2) or Bi-directional (O2 & N2) DO control |
||||
Vessel size | 1L | 3L | 5L | 10L | |
Microbial(lpm) (standard spec) |
Air | 2 | 6 | 10 | 20 |
O2 | 1 | 3 | 5 | 10 | |
N2 | 0.5 | 1.5 | 2.5 | 5 | |
CO2 | 0.5 | 1.5 | 2.5 | 5 | |
Cell culture(lpm) (standard spec) |
Air | 0.2 | 0.6 | 1 | 2 |
O2 | 0.1 | 0.3 | 0.5 | 1 | |
N2 | 0.1 | 0.3 | 0.5 | 1 | |
CO2 | 0.1 | 0.3 | 0.5 | 1 | |
Control mode | Automatic | ||||
Indicator | power indicator | ||||
gas connection | 1/4” (6.35mm) fitting for gas inlet |
* Customizing gas flow rate is available upon request.
Cat. No. | Product Description |
---|---|
FS-O-GM-MFC | Gas mixing station with four mass flow controllers for Air, O2, N2 and CO2, The standard flow rate : Air is 2vvm, O2 is 1vvm, N2 is 0.5vvm, CO2 is 0.5vvm. Customizing gas flow rate is available, please contact and discuss with local dealer before order. |
