Winpact Shaking Incubator, SI-200 series
major science is introducing our newly innovated Winpact series ,SI-200 shaking incubator
Product
major science is introducing our newly innovated Winpact series shaking incubator. It provides you the stability and durability for all your fermentation and incubation needs. The system incorporate multi-safety features to put you at your ease of mind.
Shaking Incubators SI-200 / WS-200
- Specially designed drainage channel protects the motor and inner circuitry from accidental spills
- Multiple early error-detection mechanisms ensure operators’ safety and completeness of experiment despite the malfunction
- Lab-proven superior temperature uniformity
- A wide selection of racks, holders, sticky pads and accessories provides all-ranged compatibility to cell cultivation labwares
- Automatic system shutdown in the event of system over-heating
- Sensitivity adjustable G-sensor with warning embedded for imbalance weight detection
- Programmable or continuous mode for personnel operation
- Brushless DC motor provides long and quiet operation, durable and maintenance-free usage
- Hermetic chamber design significantly reduces operation noise and enhances precise temperature control
- 2-point temperature calibration ensures high-temperature performance
* All images are for reference only, actual products might differ from the pictures above.
* Technical specifications subject to change without notice.
| Cat. No. | SI-200 | |
|---|---|---|
| Platform size | 18.1” x 18.1” (460 x 460 mm) | |
| Shaking orbit | Approx. 0.7" (19 mm) | |
| Speed range | 20-500 rpm | |
| Speed increment | 1 rpm | |
| Communication port | RS-485 | |
| External temperature probe | PT-100 | |
| Heating temperature range | Ambient +5oC to 65oC | |
| Power | 600W | |
| Temp accuracy and uniformity | ± 0.25oC at 37oC | |
| Timer | 999 (hr) : 59 (min) / Continuous | |
| Display | 3.5" Color TFT LCD screen | |
| Dimension (WxLxH) | 23.2” x 32.3” x 20.9” (Approx. 590 x 820 x 530 mm) |
|
| Weight | 154.3 lb (70 kg) | |
| Rated voltage | 110 / 220V~, 50 / 60Hz, 6.3A | |
| Certification | CE | |
| Cat. No. | Description |
|---|---|
| SI-200 | Winpact Shaking Incubator with universal platform included |
Racks and Tray
| Cat. No. | Product Description | Max. platform capacity |
|---|---|---|
| SI-200-01 | Universal platform | 1 |
| SI-200-02 | Adjustable angle tube rack ( 33 x 15 ml ) | 4 |
| SI-200-03 | Adjustable angle tube rack ( 16 x 50 ml ) | 4 |
| SI-200-04 | Universal spring rack | 2 |
| SI-200-05 | Sticky pad platform | 1 |
| SI-200-06 | Universal cushioned crossbar platform | 1 |
| PPL-04-SI-SI-200-3 | Sticky pad 20x20 cm | 4 |
Microplate and flask holder
| Cat. No. | Product Description | Max. platform capacity |
|---|---|---|
| SI-200-07 | Microplate holder | 9 |
| SI-200-08 | Flask holder, 50 ml | 52 |
| SI-200-09 | Flask holder, 125 ml | 25 |
| SI-200-10 | Flask holder, 250 ml | 25 |
| SI-200-11 | Flask holder, 500 ml | 16 |
| SI-200-12 | Flask holder, 1000 ml | 9 |
| SI-200-13 | Flask holder, 2000 ml | 5 |
 |
Universal platform Cat. No.: SI-200-01 |
 |
Sticky Pad platform Cat. No.: SI-200-05 |
 |
Adjustable angle Tube Rack ( 33 x 15ml ) Cat. No.: SI-200-02 *tube not included |
 |
Universal cushioned crossbar platform Cat. No.: SI-200-06 |
 |
Adjustable angle Tube Rack ( 16 x 50ml ) Cat. No.: SI-200-03 |
 |
Microplate holders Cat. No.: SI-200-07 (Plataforma no incluída) |
 |
Universal Spring Rack Cat. No.: SI-200-04 |
 |
Flask holder Cat. No.: SI-200-08~13 |
